| ブランド名: | BOZHONG |
|---|---|
| 証明: | ISO / TUV / DNV |
| モデル番号: | Inconel 713C |
| 最小注文数量: | 交渉可能 |
| 価格: | negotiable |
| パッケージの詳細: | 耐航性のあるパッキングまたは要求に応じて |
| 受渡し時間: | 3--10days |
| 支払条件: | L/C、T/T、ウェスタン・ユニオン、MoneyGram |
| 供給の能力: | 10000Ton/Month |
| 記述: | Inconel 713Cのニッケル合金の版 | 等級: | Inconel 713C |
|---|---|---|---|
| 密度: | 7.913 g/cmの³ | 融点: | 1260℃-1288℃ |
| ハイライト: | nickel alloy sheet,thin alloy sheet |
||
We Manufacture and Sell Inconel 713C Round Bar by Investment Casting,Bar Diameter form 6.0mm-300mm.More Detail information,Please contact us!
Inconel 713C is a nickel-chromium alloy that is ideally suited for jet engine gas turbine blades.Inconel 713C offers outstanding resistance to thermal fatigue and good castability while offering exceptional rupture strength at 1700°F (927°C).
| Alloy | % | Ni | Cr | Fe | Mn | Si | Mo | Zr | Ti | Cu | Co | Al | C | S |
| 713C | Min. | Bal | 12.0 | - | - | - | 3.8 | 0.05 | 0.5 | - | 1.8 | 5.5 | - | - |
| Max. | 14.0 | 2.5 | 0.25 | 0.5 | 5.2 | 0.15 | 1.0 | 0.5 | 2.8 | 6.5 | 0.20 | 0.015 |
| Density | 7.913 g/cm³ |
| Melting point | 1260℃-1288℃ |
●High-speed tungsten-cobalt or molybdenum-tungsten-vanadium toolsCutting lubricants:
Chlorinated, sulfurized fatty mineral oil
Rich emulsion of 10 parts water and 1 part soluble oil
Aluminum oxide
Vitrified bond of medium or soft hardness and medium open structure
Use 1 pound of sal soda with 25 gallons of water, or chemically active grinding coolant
Inconel 713C is most commonly used for jet engine gas turbine blades.
